RS1351 RES M/F 13Kohm 1% 1/4W R9,10,20,48 4
RS1353 RES M/F 3.01Kohm 1% 1/4W R50,51,57 3
RS1355 RES M/F 4.75Kohm 1% 1/4W R6 1
RS1357 RES M/F 100 ohm 1% 1/4W R54 1
RS1370 RES M/F 3.57Kohm 1% 1/4W R24 1
RS1455 RES M/F 150Kohm 1% 1/4W R35,36,49 3
RS1492 RES M/F 221Kohm 1% 1/4W R30 1
RS1505 RES M/F 475Kohm 1% 1/4W R37 1
RS1562 RES M/F 82.5Kohm 1% 1/4W R47 1
RS1585 RES M/F 475 ohm 1% 1/4W R5 1
RS2018 RES M/F 10Kohm 1% 1/4W R13,18,26 3
RS2019 RES M/F 20Kohm 1% 1/4W R2,41,58,69,70,71 6
RS2025 RES M/F 9.31Kohm 1% 1/4W R1 1
RS2099 RES M/F 6.98Kohm 1% 1/4W R21,22 2
RS2126 RES M/F 69.8Kohm 1% 1/4W R7 1
RS2128 RES M/F 6.65Kohm 1% 1/4W R8 1
RS2130 RES M/F 432 ohm 1% 1/4W R11 1
RS2131 RES M/F 536Kohm 1% 1/4W R15 1
RS2133 RES M/F 69.8Kohm 1% 1/4W R17 1
RS2136 RES M/F 53.6Kohm 1% 1/4W R19 1
RS2139 RES M/F 200 ohm 1% 1/4W R25 1
RS2140 RES M/F 619Kohm 1% 1/4W R32 1
RS2141 RES M/F 110Kohm 1% 1/4W R33 1
RS2142 RES M/F 100Kohm 1% 1/4W R34,38,53 3
RS2143 RES M/F 3.32Kohm 1% 1/4W R27,40,46,55 4
RS2144 RES M/F 1.3Kohm 1% 1/4W R42,60 2
RS2146 RES M/F 1.5Mohm 1% 1/4W R44 1
RS2147 RES M/F 249Kohm 1% 1/4W R45 1
RS2148 RES M/F 130Kohm 1% 1/4W R59 1
RS2149 RES Fuse 1Kohm 5% 1/4W T R61,62,64,66,72,73,76,78 8
RS2150 RES Fuse 0.22ohm 5% 1/2W R65,67,77,79 4
RS2151 RES M/O F/P 1Kohm 5% 2W R68 1
RS2152 RES M/F 75Kohm 1% 1/4W R81 1
RS2153 or 146-6461 Potentiometer 20Kohm 20% BASS GAIN 1
RS2154 Potentiometer 2Kohm BIAS ADJ P2 1
RS2155 RES C/F 33Kohm 5% 1/2W R43,43B 2
RS2158 RES M/F 3.3Kohm 5% 1/4W R75 1
RS2181 RES M/F 2.21Mohm 1% 1/4W R28,31 2
RS2283 RES M/O F/P 5.1Kohm 5% 5W R23 1
Miscellaneous
SC1082 SC 6-32x 3/4 Mach-Thr, Pa 2
SC1099 SC 6-32x 1/4 Mach-Thr Pan 6
SC1240 SC 6-32x 1/2 Mach-Thr Pan 4
SC1277 SC 5-20x1/2 Hi-Lo Pan Phi 2
SP1086 Clamp Insulator 2
ST1022 Standoff #6 x 5/16 Nylon 2
TH1017 Inrush Current Lititer CL1 1
VA1009 Varistor 200V MOV1 1
Electrical Parts List (120V)
Part# Description Ref Designation Qty
