Part Number Description Qty Reference Designator
051-540101-000 PNP Transistor PN:2N5401 TO-92 1 Q1
051-555100-000 NPN Transistor PN:2N5551 TO-92 1 Q17
051-640001-000 MOSFET N-Channel PN:IRF640N TO-220 (IR) 2 Q18,22
052-400080-000 Bridge Regulator PN:RS804 400V,8A 1 BR1
053-211100-000 IC;DIP,Driver PN:IR2111 8PIN (IR) 1 U7
054-000100-100 SMD DIODE PN:ES1D 200V 1A 5 D5,26,29,33,38
054-001002-100 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 1 D35
054-001501-100 SMD ZENER DIODE PN:BZX84C15 15V SOT-23 3 D6,7,9
054-007200-100 SMD IC Dual Op-amp PN:TL072CDR SO-8 2 U5,6,
054-007400-100 SMD IC; Quad Op-amp PN:TL074CDR 2 U2,3
054-011400-100 SMD Transistor PN:DTC114TKA SMT3 1 Q7
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 7 Q11,14,13,5,8,25,9
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 4 Q6,10,12,15
054-045580-100 SMD IC; Dual Op-amp PN:NJM4558M-TE3 DMP-8 1 U4
054-050601-100 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 3 D24,36,37
054-414803-100 SMD DIODE PN:LL4148 (Wishay) 12 D1-4,8,27,28,30-32,34,39,
054-540100-100 SMD Transistor PN:MMBT5401 LT1 SOT-23 3 Q20,24,26
Miscellaneous
041-115001-000 Bead Coil YT-10911 1 L5
042-010053-003 Transformer YT-10616-4 1 PT1
043-300101-000 Inductor 30uH YT-10033 1 L2
043-324300-000 Inductor 324uH YT-10778 1 L4
043-560200-000 Inductor 56uH YT-10779 1 L1
043-700101-000 Toroidal Inductor 70uH YT-10682 1 L3
044-100100-000 SMD Ferrite Bead PN:321611 600R/100MHz 1206 1
061-020000-000 Knob ABS φ20x15m/m UL94V-0 blk 2
061-314002-000 Strain Relief P/N SB4F-2 1
061-400014-000 Rubber Foot ID:6.2 OD:11.5 t=2mm blk 1
061-700044-000 Mycar 13x18mm TO-220 1
063-010012-000 Bracket for Power Transisto
r
P/N:TRK-1 1
063-321101-000 Plate 322x105.7x15mm BLK ABS-94V0 1
063-531808-000 Bucket 322x105.7x146.5mm blk (94VO) 1
065-100200-000 UL Sleeve φ2.5 F32-2.5(blk) 125 1
071-100851-000 Washer
ID=5.1 OD=12 t=1m/m
1
072-010007-000 RCA SCJ-1020 2P(G) WHT,RED 1
072-040039-000 Terminal PC205 (t=0.8m/m) T205MA 1
072-040064-000 Terminal PC250(t=0.8),T250MA 1
072-040096-000 Terminal (t=0.8mm) PC187(0.8) 1
072-040169-000 Connector 2 PIN JS-1001-2 P:2.5mm 1
072-060170-000 B.P. W / Accessory Parts 1
072-060213-000 BP Plug PN:A414B-3A Blk 1
072-060214-000 BP Plug PN:A414R-3A Red 1
073-032088-600 Black anodized
58x32x70mm
1
073-050001-000 Fuse Clip P/N:CFFH1206 1
074-020018-000 Rocker SW PN:RF1003-BB4-0 1
074-030002-000 Tolggle SW PN:L101-T2B4QE 1
074-300018-000 Relay PN:943-1C-48D 1
082-022607-000 Wire Set #26 UL1007 L=74mm Black/Wht 2P Housing 1
083-041802-009 UL Power Cord SPT-2 Black 1
093-105202-300 Fuse:UL GSL(2AG) FUSE:2A,250V,5*20mm 1 F1
181-911600-161 Wire set #16AWG UL1007
Black L=610mm
1
