Infinity PS-10 - Printed Circuit Board (PCB) Drawings

Part Number Description Qty Reference Designator
071-100851-000 Washer ID=5.1 OD=12 t=1m/m 1
072-010007-000 RCA SCJ-1020 2P(G) WHT,RED 1 CONN1
072-040039-000 Terminal PC205 (t=0.8m/m) T205MA 1 S-
072-040064-000 Terminal PC250(t=0.8),T250MA 1 S+
072-040096-000 Terminal (t=0.8mm) PC187(0.8) 1 AC1,AC3,T1,T2,AC2,SW2,SW4
072-040169-000 Connector 2 PIN JS-1001-2 P:2.5mm 1
072-060170-000 B.P. W / Accessory Parts 1 BP/IP
072-060213-000 BP Plug PN:A414B-3A RCA JAM blk 1
072-060214-000 BP Plug PN:A414R-3A RCA JAM red 1
073-032088-600 Black anodized 58x32x70mm 1
073-050001-000 Fuse Clip P/N:CFFH1206 1
074-020018-000 Rocker SW PN:RF1003-BB4-0 1
074-030002-000 Toggle SW PN:L101-T2B4QE 1 SW5,SW6
074-300018-000 Relay PN:943-1C-48D 1 K1
082-022607-000 Wire Set #26 UL1007 L=74mm blk/whe 2P Housing 1
083-041802-009 UL Power Cord SPT-2 blk 1
093-105202-300 Fuse:UL GSL(2AG) FUSE:2A,250V,5*20mm 1 F1
181-911600-161 Wire Set #16AWG UL1007 Black L=610mm 1
181-911655-135 Wire Set #16AWG UL1007
Green L=610mm
1
181-921600-000 BLK Wire #16 UL1015 T187 L:140mm 1
181-921699-000 WHT Wire #16 UL1015 T187 L:160mm 1
008-061215-000 Gasket C4305 12x15 t=5mm CR 1
008-062002-002 Gasket L-32 200x20mm t=5mm PORON 1
008-062002-012 Gasket C4305 200x20mm t=2mm CR4305 1
008-063208-000 Gasket C4305 321x8 t=1mm CR 1
008-069304-000 Gasket C4305 93x4 t=1mm CR 1
041-115001-000 Bead Coil YT-10911 1 L5
042-010053-003 Transformer YT-10616-4 1 PT1
043-300101-000 Inductor 30uH YT-10033 1 L2
043-324300-000 Inductor 324uH YT-10778 1 L4
043-560200-000 Inductor 56uH YT-10779 1 L1
043-700101-000 Toroidal Inductor 70uH YT-10682 1 L3
044-100100-000 SMD Ferrite Bead PN:321611 600R/100MHz 1206 2 FB1,FB2
24
PS-10/PS-12
