Infinity PS-12 Service Manual

Part Number Description Qty Reference Designator
024-560598-120 SMD Resistor 56K 1/8W J 0805 1 R122
024-620398-100 SMD Resistor 620R 1/8W F 0805 2 R16,18
024-680498-120 SMD Resistor 6K8 1/8W J 0805 6 R46,91,40-43
024-680598-120 SMD Resistor 68K 1/8W J 0805 6 R33,34A,31,50,52,66
024-820598-120 SMD Resistor 82K 1/8W J 0805 1 R69
024-887498-100 SMD Resistor 8K87 1/8W F 0805 1 R35A
024-910398-100 SMD Resistor 910R 1/8W F 0805 1 R110
025-010300-000 Thermister TSE-103 K L:50mm 1
026-200595-269 VR LEVEL PN:RD163121R03D-20KBx2(EJ) 1 VR2
026-500495-252 VR 5KA FREQUENCY PN:RK163111R52B-5KA (EJ) 1 VR1
Capacitors
031-100244-100 SMD Ceramic Capacitor 0u01/50V K 0805 X7R 7 C33,45,51,66,67,5,10
031-100343-100 SMD Capacitor 100pF/50V J 0805 NPO 3 C16,36,58
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R 12 C11,42-44,46-49,52,54,55,60
031-100384-100R SMD Capacitor 0u1/250V K 1206 X7R 2 C3,7
031-220243-103 SMD Capacitor 0u022/50V J 0805 X7R 1 C40
031-220344-100 SMD Capacitor 220pF/50V J 0805 NPO 5 C14,15,20,21,19
031-330444-300 SMD Capacitor 3300pF/50V K 0805 X7R 1 C34
031-470244-102 SMD Capacitor 0u047/50V K 0805 X7R 2 C62,59
031-560243-100 SMD Capacitor 56pF/50V J 0805 NPO 2 C57,61
031-560343-102 SMD Capacitor 560pF/50V J 0805 NPO 1 C56
032-100484-200 Mylar Capacitor 1uF/250V K P:15 2 C70,C70B
032-270343-301 Mylar Capacitor 0u27/63V J P:5 1 C29
032-820244-200 Mylar Capacitor 0u082/100V K (R) 1 C30
033-470464-270 NPE Capacitor 4u7/100V K10 (R)1015 GNE 1 C73
033-680464-270 NPE Capacitor 6u8/100V K10 (R)1020 GNE 1 C72
034-100525-300 Electrolytic Capacitor 10uF/25V M (R)0511 P:5 1 C35
034-100625-300 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 1 C64
034-220525-301 Electrolytic Capacitor 22uF/25V M (R)5x11 P:5 5 C4,9,41,50,53
034-220615-301 Electrolytic Capacitor 220uF/16V M (R)0611 P:5 1 C37
034-330515-000 Electrolytic Capacitor 33uF/16V M (R)0511 P:5 1 C39
034-330525-300 Electrolytic Capacitor 33uF/25V M (R)0511 P:5 1 C1
034-330615-300 Electrolytic Capacitor 330uF/16V M (R)0812 P:5 2 C12,78
034-330780-300 Electrolytic Capacitor 3300uF/80V M (R)22x48 2 C6,8
034-470415-301 Electrolytic Capacitor 4u7/50V M (R)0511 P:5 1 C2
034-470615-301 Electrolytic Capacitor 470uF/16V M (R)0812 P:5 1 C65
035-100393-301 Mylar Capacitor 0u1/63V J P:5 2 C28,C2A
035-220393-300 PE Capacitor 0u22/63V J P:5 1 C27
035-470293-300 PE Capacitor 0u047/63V J P:5 1 C1A
035-470353-301 ESKCapacitor 0u47/63V J P:5m/m 2 C25,26
038-100363-300 MPE Capacitor 0u1/100V J 2 C68,69
039-100390-100 Safety Capacitor 0u1/275V PN:XG275M104VSL7 1
Semiconductors
050-505200-001 LED PN:LT-2402-21 1
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 2 Q2,Q16
051-003100-000 NPN Transistor PN:TIP 31C TO-220 (MOSPEC) 1 Q4
051-005600-100 PNP Transistor PN:MPSW56RLRA TO-92 1 Q3
051-222200-100 NPN Transistor PN:MPS2222ARLRA TO-92 1 Q21
051-290700-100 PNP Transistor PN:MPS2907A RLRA TO-92 2 Q19,23
PS-10/PS-12
18
