Infinity PS-12 Service Manual

PS-10/PS-12
Rear Panel
CONTROLS AND CONNECTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CROSSOVER
FREQUENCY
LEVEL
LINE LEVEL IN
PHASE
Min
Max
L
R
L R
For LFE use L or R
Green: On
Red: Stand-By
+ –
50Hz
0º
80Hz
150Hz
POWER
ON
¡
£
¢
∞
§
•
™
LFE NORMAL
180º
HIGH
LEVEL
IN
¶
120V
60Hz
OFF
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL 
SHOCK DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVERTISSEMENT: POUR PRÉVENIR LES RISQUES D'INCENDIE OU DE CHOC 
ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA PLUIE OU A L'HUMIDITÉ.
NRTL/C
CSA 22.2
UL1492
¡
Subwoofer-Level Control
™
LFE/Normal Selector
£
Phase Switch
¢
Crossover Adjustment
∞
Line-Level/LFE Input
§
Speaker-Level Inputs
¶
Power Switch
•
Status LED
PS-10/PS-12
6
