Infinity PS-12 Service Manual

PS-10 Electrical Parts List 120V
Part Number Description Qty Reference Designator
Resistors
020-000098-400 Carbon Film 0R 1/8W 4 C22-C24,C31
020-220497-120 Carbon Film 2K2 1/4W J 1 R11
021-100401-120 MOF Resistor 1K 1W J 1 R103
021-220202-120 MOF Resistor 22R 2W(S) J MB Type 15x8 1 R10
021-240405-020 MOF Resistor
2K4/5WS J 17x6
4 R6,9,R7A,R9A
022-500003-020 Resistor KNP 0R05 3WS J FK Type 1 R104
024-000098-120 SMD Resistor 0R 1/8W J 0805 1 R68
024-100298-120 SMD Resistor 10R 1/8W J 0805 2 R81,82
024-100398-120 SMD Resistor 100R 1/8W J 0805 1 R62
024-100498-120 SMD Resistor 1K 1/8W J 0805 8 R79,83,92,95,96,105,108,,65
024-100598-100 SMD Resistor 10K 1/8W F 0805 2 R20,21
024-100598-120 SMD Resistor 10K 1/8W J 0805 8 R2,17,19,37,54,58,63,71
024-100698-100 SMD Resistor 100K 1/8W F 0805 4 R22-25
024-100698-120 SMD Resistor 100K 1/8W J 0805 2 R3,112
024-110598-100 SMD Resistor 11K 1/8W F 0805 1 R98
024-137698-100 SMD Resistor 137K 1/8W F 0805 1 R32
024-150498-120 SMD Resistor 1K5 1/8W J 0805 1 R67
024-160798-120 SMD Resistor 1M6 1/8W J 0805 1 R121
024-162398-101 SMD Resistor 162R 1/8W F 0805 1 R6A
024-169698-100 SMD Resistor 169K 1/8W F 0805 1 R4A
024-180598-100 SMD Resistor 18K 1/8W F 0805 1 R29
024-187698-100 SMD Resistor 187K 1/8W F 0805 1 R45
024-200598-120 SMD Resistor 20K 1/8W J 0805 1 R94
024-220398-120 SMD Resistor 220R 1/8W J 0805 1 R90
024-220498-121 SMD Resistor 2K2 1/8W J 0805 3 R1,87,61
024-220598-120 SMD Resistor 22K 1/8W J 0805 2 R118,39
024-220798-120 SMD Resistor 2M2 1/8W J 0805 1 R80
024-221498-100 SMD Resistor 2K21 1/8W F 0805 1 R5A
024-237598-120 SMD Resistor 23K7 1/8W F 0805 1 R48
024-270498-120 SMD Resistor 2K7 1/8W J 0805 2 R73,64
024-300398-120 SMD Resistor 300R 1/8W J 0805 1 R55
024-300598-120 SMD Resistor 30K 1/8W J 0805 1 R56
024-309398-100 SMD Resistor 309R 1/8W F 0805 1 R2A
024-330498-120 SMD Resistor 3K3 1/8W J 0805 8 R7,8,12-15,59,28
024-330598-120 SMD Resistor 33K 1/8W J 0805 2 R4,5
024-332498-100 SMD Resistor 3K32 1/8W F 0805 2 R26,27
024-390498-120 SMD Resistor 3K9 1/8W J 0805 1 R93
024-390598-120 SMD Resistor 39K 1/8W J 0805 1 R77
024-430498-120 SMD Resistor 4K3 1/8W J 0805 1 R78
024-432498-100 SMD Resistor 4K32 1/8W F 0805 1 R36
024-453598-100 SMD Resistor 45K3 1/8W F 0805 1 R30
024-470298-120 SMD Resistor 47R 1/8W J 0805 2 R101,102
024-470398-120 SMD Resistor 470R 1/8W J 0805 3 R76,99,100
024-470498-120 SMD Resistor 4K7 1/8W J 0805 2 R85,86
024-470598-120 SMD Resistor 47K 1/8W J 0805 4 R44,47,49,107
024-470698-120 SMD Resistor 470K 1/8W J 0805 1 R70
024-470798-120 SMD Resistor 4M7 1/8W J 0805 1 R60
024-510398-120 SMD Resistor 510R 1/8W J 0805 1 R57
024-549498-100 SMD Resistor 5K49 1/8W F 0805 1 R38
PS-10/PS-12
17
