Infinity PS-8 Service Manual

Part number Description Reference Designator Qty
Semiconductors
192-027c1815gr Transistor 2SC1815GR NPN Q102,111,112,113,118,201,206,207 8
192-028a1015gr Transistor 2SA1015GR PNP Q114,116 2
192-1672n5551 Transistor 2N5551 NPN Q103,109 2
192-1682n5401 Transistor 2N5401 PNP Q104,110 2
197-131n4148 Diode 1N4148 26mm D101,103,105,108 4
199-15000335 Zener diode 3.3V 1/2W 52mm D102,213 2
199-15000625 Zener diode 6.2V 1/2W 52mm D106,107 2
199-15001605 Zener diode 16V 1/2W 52mm D109 1
192-027c1815gr Transistor 2SC1815GR NPN Q301,302 2
197-131n4148 Diode 1N4148 26mm D301,302 2
190-16t1074cn I.C TL074CN ST QUAD OP-AMP U301 1
190-06m4558d I.C. OPA 4558D DUAL OP-AMP U101,203 2
190-16tl074cn I.C TL074CN ST QUAD OP-AMP U201,202 2
192-991d669a Transistor HI-SINCERITY HSD669A NPN Q106 1
192-992b649t Transistor HSB649T PNP Q105 1
192-021c1815gr Transistor 2SC1815GR NPN Q101,115 2
192-021tip35c Transistor TIP35C NPN Q107 1
192-022tip36c Transistor TIP36C PNP Q108 1
192-201d882y Transistor KSD882Y NPN Q117 1
192-202b772y Transistor KSB772Y PNP Q119 1
197-00kbl405 Bridge rectifier 4A 500V KBL405 D110 1
197-101n4002 Diode 1N4002 D104 1
197-131n4148 Diode 1N4148 26mm D117,118 2
197-131n4148 Diode 1N4148 26mm D116 1
195-10204hgw
LED 204HGW 3
1
190-16tl074cn I.C TL074CN ST QUAD OP-AMP U201,202 2
Capacitors
132-104kb70 CAPACITOR 0.1uF 275v+/-10% POWER SW 1
129-a474j633 Plastic cap. 0.47U 63V ±5% MSC C221,222 2
135-4688m50 Electronic cap. 6800U/50V C121,122 2
135-3107m16 Electronic cap. 100uF 16V ±20% C110 1
132-223ja03 Mylar capacitor 0.022uF 100V ±5% C123,127 2
130-2b102k503 Disc capacitor 1000P 50V ±10% C116 1
130-2b221k503 Disc capacitor 220P 50V ±10% C204,205,207,208,210,211,212,214,220,230,200,249 12
130-2f104z503 Disc capacitor 0.1U 50V +80/-20% C108,113,115,119,232,242,244,245,246,252,254 11
130-3f473m503 Disc capacitor 0.047U 50V ±20% C106 1
130-sl470k503 Disc capacitor 47P 50V ±10% C229 1
132-103j503 Mylar capacitor 0.01U 50V ±5% C223,224 2
132-104j503 Mylar capacitor 0.1U 50V ±5% C107,215,217 3
132-223ja03 Mylar capacitor 0.022uF 100V ±5% C124,125,126,128 4
135-3105m50 Electronic cap. 1U 50V ±20% C105,112,228 3
135-3106m50 Electronic cap. 10uF 50V ±20% C201,202,206,213,219,231,241,243,251,253 10
135-3107m16 Electronic cap. 100uF 16V ±20% C109,117,120,233,234 5
135-3226m50 Electronic cap. 22U 50V ±20% C114,118,225 3
135-3227m10 Electronic cap. 220U 10V ±20% C129,130 2
135-3227m16 Electronic cap. 220U 16V ±20% C111 1
135-3476m25 Electronic cap. 47U 25V ±20% C103 1
129-a224j633 Plastic cap. 0.22uF 63V ±5% MSC C218 1
129-a564j633 Plastic cap. 0.56uF 63V ±5% C216 1
130-2f104z503 Disc capcitor 0.1U 50V +80/-20% C305,306 2
132-103j503 Mylar capcitor 0.01U 50V ±5% C302,303 2
135-3226m50 Electronic cap. 22U 50V ±20% C301,340 2
135-3476m25 Electronic cap. 47U 25V ±20% C304 1
PS-8 (serial # ME0683-16316 and below)
11
