Part number Description Reference Designator Qty
Miscellaneous
193-3m2520 Piezo TO-3P 25x20mm Q107,108 2
162-50259201 WIRE ASS'Y 2 PIN 250mm red/white LED1 1
351-AM03014A094 Screw M3*14
352-AM03008D040
Screw 3*8
361-FE-00051 Transistor 14.2*8.0*5.2t=1.6mm
323-AL-00020 HEAT SINK 65*32*31
361-NYL-00054 Transistor SW06002
174-2psz406g1 JACK S-8071 JK203 1
162-80098201 Single line wire 90mm grey 28AWG SW301 1
162-50289001 Cable ass'y 280mm AWG26WHT
175-9f40hr2 Contactor 40pin pitch=2.54mm P301 1
171-udhss124d Relay 5A 24V UDH-SS124D RY101 1
174-0300390g JACK JE0300390G JK202 1
175-1c07v01 Contactor 7PIN PITCH=2.5mm P101 1
175-1d02v01 Contactor 2PIN PITCH=3.96mm P102 1
175-1d03v01 Contactor 3 PIN PITCH=3.96mmJST-VH P103 1
180-tms7210v SWITCH SLIDE 6PIN MS7210V SW201 1
150-e8604107 TRANSFORMER EI-86 60Hz 120v
152-u602015 PWR CABLE/W/ POLARITY SVT FT-26FT
154-u25006t0 FUSE 2.5A 250V 20MM FS101 1
155-520020 FUSE HOLDER R3-11
162-10082007 WIRE RED 18AWG 80MM 8MM#1015
162-50652003 WRIE 650MM RED=205# 0.5TBLK=110# 0.5t
176-wjcel CLOSE TERMINAL CE-1
180-prf1003S POWER SWITCHER ROCK RF-1003-BB2-OH
A
SW101 1
350-EM04012D024
4*12 SCREW
351-HM04016A218 M4*16 SCREW
351-AM03008A079 M3*8 SCREW
352-AM03010D065 3*10 SCREW P
352-AM03008D040
3*8 SCREW B
354-GM04002 M4 SCREW CAP WITH DENT GASKET
302-AL-00406 AL BACK BOARD 300*200*2.5t
362-FE-00013 PCB BRACKET L TYPE T=1.6MM
323-AL-00106 HEAT SINK 117.5*71.5*25 POLARITY
311-ABS-00028 PLASTIC KNOB 46077-W, SOFT PVC
306-ABS-00177 BACK BOARD 198*298*102MM
333-EVA-00783 GASKET W 198*12*2.0T
333-EVA-00807 GASKET L 274*12*2.0T
333-EVA-00826 GASKET W 274*12*1.0T
333-EVA-00835 GASKET L 274*12*1.0T
320-RUB-00033 RUBBER GASKET 25*21*4T
123-14j70d FERRITE CORE U-16.3*8.2*13(J70)+CASE
337-CU-00101 BRASS BAR 65L*50W
333-EVA-00761 GASKET 18*9*2T
ADDENDUM: Changes to serial # ME0683-16317 and above
Comment included
135-3225m50 Electronic cap. 2.2uF 50V C219 (Change in Value) 1
110-16562j26 Resistor 11.3k 1% R224 (Now attached from U301 pin 10 or 13 to GRND) 1
116-164991f26 Resistor 4.99K 1% R234 (Change in Value) 1
110-16333j26 Resistor 33K R305 (New - not previously installed) 1
PS-8 (serial # ME0683-16316 and below)
