INFINITY REFERENCE
4
°
3-channel operation: Connect the stereo speakers to the Front terminals, as described above. Connect the single speaker’s +
lead to the Rear L+ terminal, and the - lead to the Rear R- terminal.
°
2-channel (bridged) operation: Connect one speaker’s + lead to the Front L+ terminal, and the - lead to the Front R- terminal
Connect the other speaker’s + lead to the Rear L+ terminal, and the - lead to the Rear R- terminal.
Left front speaker Right front speaker
4-ohm subwoofer
4-ohm subwoofer4-ohm subwoofer
