Infinity Reference 5350A Service Manual

1 2 3 4 5 6 78
A
B
C
D
8
7654321
D
C
B
A
OP
OP OP
11 20 200 11 20050
AMP
SPEAKER
BALANCED
INPUT
UNIT
BALANCED
INPUT
UNIT
GAIN CONTROL
BASS BOOST
VARIABLE
0dB--6dB/50HZ
MODEL FREQ
VARIABLE LP
11HZ--200HZ/12dB
MAIN AMP
SUB
2ohm/4ohm
INPUT FL
+
-
Battery
+VAMP2
-VAMP2
+V1
-V1
+VOP
-VOP
POWER SUPPLY
OP OP
11 32 80K
AMP
SPEAKER
BALANCED
INPUT
UNIT
GAIN CONTROL
MODEL FREQ
VARIABLE LP
32HZ--320HZ/12dB
MAIN AMP
FL
2ohm/4ohm
320
INPUT RL
OP OP
11 32 80K
AMP
SPEAKER
BALANCED
INPUT
UNIT
GAIN CONTROL
MODEL FREQ
VARIABLE LP
32HZ--320HZ/12dB
MAIN AMP
RL
2ohm/4ohm
320
OP
SPEAKER
BTL-4ohm
+VAMP1
-VAMP1
+V2
-V2
INPUT FR
OP OP
11 32 80K
AMP
SPEAKER
BALANCED
INPUT
UNIT
GAIN CONTROL
MODEL FREQ
VARIABLE LP
32HZ--320HZ/12dB
MAIN AMP
FR
2ohm/4ohm
320
INPUT RR
OP OP
11 32 80K
AMP
SPEAKER
BALANCED
INPUT
UNIT
GAIN CONTROL
MODEL FREQ
VARIABLE LP
32HZ--320HZ/12dB
MAIN AMP
RR
2ohm/4ohm
320
OP
SPEAKER
BTL-4ohm
INPUT SUB1
INPUT SUB2
OP
OP
OP
OP
DW GNO:
PART NO:
PART NAME:
PRODUCT MODE:
SCALE: 1:1
UNIT: MM
SIZE: A4
REV: 1.0
DRAWN BY:
CHECKED BY:
APPROVED BY:
DATA:
DATA:
DATA:
BLOCK DIAGRAM
REF5350a
ECN NO
DESCRIPTON
DATAAPPROVED
JING HUI CHEN
2007.1.25
7
5350a Reference Series

Infinity Reference 5350A Specifications

General

Bass boost	0 - 6 dB
Damping factor	6.3
Amplifier class	D
Frequency range	10 - 100000 Hz
Built-in crossover	Yes
Crossover frequency	200 Hz
Audio output channels	5.1 channels
Peak power per channel	332 W
Signal-to-Noise Ratio (SNR)	85 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	89 W
RMS power output per channel (2 Ohm)	60 W
RMS power output per channel (4 Ohm)	50 W
XLR in	No
Audio (L/R) in	2
USB 2.0 ports quantity	0
Speakers connectivity type	Clamp terminals
Purpose	Car
Material	Aluminum
Cooling type	Passive
Product color	Aluminium, Grey
Volume control	Rotary
Remote control type	W
Connectivity technology	Wired
Maximum current	75 A
DC input voltage	10 - 14 V

Weight and Dimensions

Depth	421 mm
Width	229 mm
Height	68 mm
