Infinity SUB450 - Page 13

Part Number Description Qty Reference Designator
Capacitors
130-3f472md00 Ceramic Cap 4700pf 400v +/- 20%
1 ON POWER SWITCH
130-2b101k503 CD 100P 50V 10%
3 C207,214,220
130-2b102k503 CD 1000P 50V 10%
2 C116,203
130-2b221k503 CD 220P 50V 10%
6 C204,205,210,211,212,230
130-2b681k503 CD 680P 50V 10%
1 C208
130-2f104z503 CD 0.1U 50V +80/-20%
13
C108,113,115,119,232,235,236,237,239,240,241,305,
306
130-3f473m503 CD 0.047U 50V 20%
2 C106,209
130-sl470k503 CD 47P 50V 10%
1 C229
132-103j503 MC 0.01U 50V 5%
2 C223,224
132-104j503 MC 0.1U 50V 5%
4 C107,218,221,222
132-223ja03 MC 0.022U 100V 5%
5 C124,125,126,128,215
132-473j503 MC 0.047U 50V 5%
2 C216,217
132-103j503 MC 0.01U 50V 5%
2 C302,305
135-3105m50 EC 1U 50V 20%
3 C105,112,228
135-3106m50 EC 10U 50V 20%
6 C201,202,206,213,219,231
135-3107m16 EC 100U 16V 20%
6 C109,117,120,234,238,242
135-3226m50 EC 22U 50V 20%
4 C114,118,225,301
135-3227m10 EC 220U 10V 20%
2 C129,130
135-3227m16 EC 220U 16V 20%
2 C111,233
135-3476m25 EC 47U 25V 20%
1 C103,304
132-223ja03 MC 0.022U 100V 5%
2 C123,127
135-3107M16 EC 100U 16V 20%
1 C110
135-4688m50 EC 6800U 50V 20% D25X45mm
2
C121,122
Semiconductors
192-027c1815gr TR 2SC1815GR NPN
8 Q102,111,112,113,118,206,207,208
192-028a1015gr TR 2SA1015GR PNP
2 Q114,116
192-1672n5551 TR 2N5551 NPN
2 Q103,109
192-1682n5401 TR 2N5401 AI-PNP 500mA TO-92
2 Q104,110
197-131n4148 DIODE 1N4148 26mm
9 D101,103,105,108,201,202,206,207,208
199-15000335 ZENER 3.3V 1/2W 26mm
2 D102,205
199-15000625 ZENER 6.2V 1/2W 26mm
2 D106,107
199-15001605 ZENER 16V 1/2W 26mm
1 D109
192-021c1815gr TR 2SC1815GR NPN
4 Q101,115
192-991d669a TR 2SD669A NPN
1 Q106
192-021tip35c TR TIP35C NPN
1 Q107
192-992b649t TR 2SB649A PNP
1 Q105
192-022tip36c TR TIP36C PNP
1 Q108
192-201d882y TR KSD882Y PNP
1 Q117
192-202b772y TR KSB772Y PNP
1 Q119
190-06m4558d IC OPA 4558D DUAL OP-AMP
2 U101,203
190-16tl074cn IC TL074CN ST QUAD OP-AMP
3 U201,202,301
195-10204hgw LED 204HGW
1 D209
197-101n4002 DIODE 1N4002
1 D104
197-131n4148 DIODE 1N4148
2 D301,302
