Infinity SUB450 User Manual

TSS-450
SUBWOOFER CONNECTIONS
If your receiver/processor does not contain
a Dolby Digital or DTS processor but has a
subwoofer output:
If your receiver/processor does not have
subwoofer outputs for the left and right
channels or an LFE output:
If you have a Dolby* Digital or DTS
®
receiver/
processor with a low-frequency-effects (LFE)
or subwoofer output:
HIGH LEVEL
+ – – +
SUBWOOFER
LEVEL
OUT
IN
L R
LINE LEVEL IN
LFE
L
R
AUTO ON
MIN MAX
GREEN: ON
RED: STANDBY
SUBWOOFER OR
LFE OUTPUT
Set line-level/LFE switch to “LFE.”
HIGH LEVEL
+ – – +
SUBWOOFER
LEVEL
OUT
IN
L R
LINE LEVEL IN
LFE
L
R
AUTO ON
MIN MAX
GREEN: ON
RED: STANDBY
RECEIVER/PROCESSOR
HIGH LEVEL
+ – – +
SUBWOOFER
LEVEL
OUT
IN
L R
LINE LEVEL IN
LFE
L
R
AUTO ON
MIN MAX
GREEN: ON
RED: STANDBY
RECEIVER/AMPLIFIER
Front Speaker Output
LEFT RIGHT
+ – – +
LEFT SPEAKER
– +
RIGHT SPEAKER
– +
15' subwoofer
cable included
15' subwoofer
cable included
Set line-level/LFE switch to “Normal.”
NOTE:If your receiver/processor has only one sub out,
you may use either the L or R input.
INFP1408TSS-450 OM 8/11/03 4:38 PM Page 8
SUB450
4

Infinity SUB450 Specifications
