Infinity SUB450 User Manual

SUB 450 Electrical Parts List
Part Number Description Qty Reference Designator
Resistors
110-14122j26 RES 1.2K 1/4W 5% CF 26mm
1 R265
110-14472j26 RES 4.7K 1/4W 5% CF 26mm
4 R147,150,201,202
110-14681j26 RES 680 1/4W 5% CF 26mm
2 R148,151
110-16101j26 RES 100 1/6W 5% CF 26mm
4 R120,213,214,215
110-16102j26 RES 1K 1/6W 5% CF 26mm
2 R124,254
110-16103j26 RES 10K 1/6W 5% CF 26mm
25
R134,209,212,216,217,220,221,222,225,226,228,229,
230,232,235,240,260,264,301,303,304,308,309,314
110-16104j26 RES 100K 1/6W 5% CF 26mm
1 R231
110-16105j26 RES 1M 1/6W 5% CF 26mm
2 R143,259
110-16123j26 RES 12K 1/6W 5% CF 26mm
2 R135,139
110-16124j26 RES 120K 1/6W 5% CF 26mm
1 R233
110-16151j26 RES150 1/6W 5% CF 26mm
1 R253
110-16152j26 RES 1.5K 1/6W 5% CF 26mm
6 R103,123,136,137,141,142
110-16153j26 RES 15K 1/6W 5% CF 26mm
5 R118,145,152,154,234
110-16154j26 RES 150K 1/6W 5% CF 26mm
2 R131,252
110-16181j26 RES 180 1/6W 5% CF 26mm
2 R111,114
110-16182j26 RES 1.8K 1/6W 5% CF 26mm
1 R153
110-16183j26 RES 18K 1/6W 5% CF 26mm
2 R227,262
110-16223j26 RES 22K 1/6W 5% CF 26mm
10 R128,129,133,237,238,255,256,263,310,312
110-16273j26 RES 27K 1/6W 5% CF 26mm
1 R223
110-16205j26 RES 2M 1/6W 5% CF 26mm
1 R257
110-16332j26 RES 3.3K 1/6W 5% CF 26mm
5 R106,107,144,236,258
110-16333j26 RES 33K 1/6W 5% CF 26mm
1 R305
110-16392j26 RES 3.9K 1/6W 5% CF 26mm
2 R105,108
110-16393j26 RES 39K 1/6W 5% CF 26mm
1 R126
110-16470j26 RES 47 1/6W 5% CF 26mm
4 R112,113,115,116
110-16471j26 RES 470 1/6W 5% CF 26mm
1 R140
110-16472j26 RES 4.7K 1/6W 5% CF 26mm
5 R110,125,130,207,208
110-16473j26 RES 47K 1/6W 5% CF 26mm
5 R101,219,249,250,251
110-16474j26 RES 470K 1/6W 5% CF 26mm
1 R307
110-16512j26 RES 5.1K 1/6W 5% CF 26mm
2 R210,211
110-16513j26 RES 51K 1/6W 5% CF 26mm
1 R224
110-16560j26 RES 56 1/6W 5% CF 26mm
1 R117
110-16563j26 RES 56K 1/6W 5% CF 26mm
1 R104
110-16682j26 RES 6.8K 1/6W 5% CF 26mm
1 R109
110-16751j26 RES 750 1/6W 5% CF 26mm
2 R311,313
110-16755j26 RES 7.5M 1/6W 5% CF 26mm
1 R306
110-16913j26 RES 91K 1/6W 5% CF 26mm
4 R203,204,205,206
110-10821jk1 RES 820 1W 5% 5mm
1 R132
110-122r2j15 RES 2.2 1/2W 5% 15mm
1 R127
110-20331jk2 Resistor 330Ω 2W ±5%
1 R146
110-20331jk3 Resistor 330Ω 2W ±5%
1 R149
114-03302m0 Semi-solid resistor 3K 0.3W ±20%
1
R138
115-h503a101 VR D16 50K/1 A LEVEL POT
1 VR201
110-16153j26 Resistor 15K 1/6W ±5% CF 26mm
1 R302
113-50r10j20 Resistor 0.1Ω 5W ±5%
2
R121,122
11

Infinity SUB450 Specifications

General

Brand	Infinity
Model	SUB450
Category	Subwoofer
Language	English
