Accessing the Appliance
28 Infoblox Installation Guide
The Infoblox GUI also displays detailed status of the RAID array. In the event of a disk failure, you must replace the
failed disk with one that is qualified and shipped from Infoblox and has the same disk type as the rest of the disks
in the array. The appliance displays information about mismatched disks in the
Description
column in the Detailed
Status panel. The disk type can be one of the following:
IB-Type 1: Infoblox supported disk type
IB-Type 2: Infoblox supported disk type
Unk: Unknown disk type that Infoblox does not support
All disk drives in the array must have the same disk type for the array to function properly. You can have either
IB-Type 1 or IB-Type 2, but you cannot mix both in the array. When you have a mismatched disk in the array, you
must promptly replace the disk with a replacement disk from Infoblox to avoid operational issues.
Appliance Front Panel
The disk drives are located on the right side of the appliance front panel. To the right of each drive there are two
LEDs that displays the connection and activity status of each drive.
Table 4 Disk Drive LEDs
In addition, the front panel LCD scrolls and displays the disk array status every 20 seconds.
LED Color Condition Action
Blue Disk is connected and
operational
None
Green Disk operating normally None
Dark Disk has failed or not inserted Verify the failure in the Infoblox GUI or CLI. Remove the disk
and replace with a functional disk drive. Note that the drive
rebuilds with its twin.
