System, Environmental, and Power Specifications
For the Infoblox-2000-A Appliance 9
System, Environmental, and Power Specifications
System specifications describe the physical characteristics of each appliance. Environmental specifications
describe the temperature and moisture limits it can withstand. Power specifications describe the electrical range
within which the appliance circuitry can operate.
System Specifications
• Form Factor: 3-U rack-mountable appliance
• Dimensions: 5.25” H x 17.6” W x 22.75” D (13.4 cm H x 44.8 cm W x 57.8 cm D)
• Weight: Approximately 48 pounds (21.8 kg)
• Ethernet Ports: MGMT, HA, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-T
• Serial Port: DB-9 (9600/8n1, Xon/Xoff)
• USB Ports: Two USB 2.0 compliant/1.1
• LCD Panel: LCD (liquid crystal display) with input buttons
Environmental Specifications
• Operating Temperature: 41 to 95 degrees F (5 to 35 degrees C)
• Storage Temperature: 23 to 122 degrees F (-5 to 50 degrees C)
• Relative Humidity: 5% to 95%, relative humidity (non-condensing)
• Average Heat Dissipation: 1400 BTU (British Thermal Units)/hour
Electrical Power Specifications
• AC Power Supply
— Model Number: RAK540MV-ZZ
— Input Voltage
— U.S.: 100 – 240 VAC switchable, 50 – 60 HZ, 8 A, redundant, dual input
— Europe: 208 – 265VAC, 50 – 60Hz, 4 A, redundant, dual input
— Output Power: 540 watts each
