InFocus in122 User Manual

11
Shutting down the projector
Auto Off Time
The projector also has an Auto Off Time feature that automatically turns the projector off
after no active sources are detected and no user interaction with the projector is performed
for 30 minutes. By default, this feature is off. You can change the length of time, see
page 29.
Turning off the projector
To turn the projector off, press the Power button on the remote or keypad. The lamp turns
off and the Power LED blinks blue for 1 minute while the fans continue to run to cool the
lamp. If the Power Saving Mode feature is on and when the lamp has cooled, the LED lights
blue and the fans stop. If the Power Saving Mode feature is off and when the lamp has cooled,
the LED blinks blue and the fans stop. Unplug the power cable to completely power off the
projector.
Troubleshooting your setup
If your image appears correctly on the screen, skip to the next section. If it does not,
troubleshoot the setup.
The Status Indicator Panel on top of the projector indicates the state of the projector and
can h
elp you troubleshoot
TEMP/LAMP
POWER
.
Table 3: Status indicator light behavior and meaning
Status Indicator Light Meaning
POWER: Solid blue
POWER: Blinking blue
1. If the Power Saving Mode feature is on,
the projector is plugged in.
2. The projector is on and initialized.
3. The projector is in normal operation.
1. If the Power Saving Mode is off, the
p
roje
ctor is plugged in.
2. The projector is powering down and
the fans are cool
ing the projector.
POWER: Blinking blue
TEMP/LAMP: Blinking pink
POWER: Solid blue
TEMP/LAMP: Blinking pink
The projector fan(s) are not operating
correctly and the p
rojector has been shut
down.
The lamp failed to ignite.
Contact Technical Support if the problem
pers
ists. Visit www.infocus.com/support
to contact service.
POWER: Solid blue
TEMP/LAMP: Blinking red
The lamp has reached its end of life and
must be replaced. The lamp will
continue
to operate until it fails.
Contact Technical Support. Repair may be
needed.
PO
WER: Solid blue
TEMP/LAMP: Blinking blue
1. The projector is overheating and the
lamp will be shut off. T
he fans will
continue to run.
2. The projector will not turn back on
until th
e cooling process is complete.

InFocus in122 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.5 - 11.9 m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	4000:1
Screen size compatibility	40 - 303 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	100 kHz
Horizontal synchronization (min)	31 kHz
Projector brightness (economic mode)	2500 ANSI lumens
Focus	Manual
Offset	15 %
Throw ratio	1.97 - 2.17:1
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	230 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
RMS rated power	2 W
Number of built-in speakers	1
HDMI version	1.4
Audio (L/R) in	-
USB connector type	Mini-USB B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Noise level	30 dB
Preset modes	Beige wall, Blackboard, Bright, Cinema, Custom, Presentation, Whiteboard
Certification	UL, c-UL, FCC, CE
Password protection type	User
Noise level (economic mode)	28 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	235 W
Operating altitude	0 - 3048 m
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, VGA

Weight and Dimensions

Depth	235 mm
Width	284 mm
Height	70 mm
Weight	2170 g
Package width	330 mm
Package height	150 mm
Package weight	3670 g
