Using LP Utilities
38 LitePro 580 User’s Guide
Adjusting the Video settings
1. Double-click the Video control panel icon.
• The Video settings dialog box appears.
2. Make the desired changes.
• Click any active arrow to increase or decrease a value.
• Click an option button under Mode to select one of four
options.
• Click “Reset” to reset the value to their original settings.
3. Close the dialog box.
• Click “OK” to save any changes and close the dialog box.
You cannot access this dialog when computer input
is being displayed.
Adjusts the sharpness
of the image
Adjusts the color
density of the image
Selects video
broadcast format.
Resets changes to default settings Closes dialog box
Adjusts image
contrast
Adjusts image
brightness
Adjusts the tint
Indicates source
of input
