inform PDSP 33080 User Manual

33
A38
VDC NOT OK
DC bus voltage is out of its normal range
A39
T-AMP HIGH
Ambient temperature exceeds its upper limit
A40
GENSET ON
Generator friendly operation is activated
A41
EMG STOP ON
Emergency stop is activated
A42
MINOR ALR
Minor Alarm
A43
MAJOR ALR
Major Alarm
A44
BATT TS FAIL
Batteries failed in the battery test
A45
BATT CR OPEN
Battery Circuit Breaker is open
A47
INV RX T-OUT
Communication between the inverter and the front panel is lost
A48
REC RX T-OUT
Communication between the rectifier and the front panel is lost
All alarms except VSEC NOT OK are minor.
MEASUREMENTS MENU
MEASUREMENT
DEFINITION
LD
=
XXX,XXX,XXX
%
Ratio of the actual inverter active power of each line to its nominal
value*
1
Vsc
=
XXX,XXX,XXX
V
Output line/neutral voltages*
1
Isc
=
XXX,XXX,XXX
A
Output line currents*
1
Fo
=
XX.X
Hz
Frequency of output line/neutral voltages
Vby
=
XXX,XXX,XXX
V
Bypass line/neutral voltages*
1
Vin
=
XXX,XXX,XXX
V
Input line/neutral voltages
Iin
=
XXX,XXX,XXX
A
Rectifier Output Current
Fin
=
XX.X
Hz
Frequency of input line/neutral voltages
Vdc
=
XXX,XXX
V
Positive and negative DC bus voltages
Vbat
=
XXX,XXX
V
Positive and negative battery branch voltages
Ibat
=
±XXX,±XXX
A
Positive and negative battery branch currents
Positive during charge, negative during discharge
Tbat
=
XXX
°C
Ambient temperature
COMMANDS MENU
PRIORITY
=
INVRTR/BYPASS
Selects the priority of normal and bypass operation modes
Push ENTER to switch between INVRTR and BYPASS
START B. TEST
Push ENTER to start battery test
BUZZER
=
ENBLD/DSBLD
Enable or disable the buzzer
Push ENTER to switch between ENBLD and DSBLD
COMM
=
RS232/RS422
Push ENTER to switch between RS232/RS422
communication
EXTCMNDS
Push ENTER 3 times to enter this submenu
