4.2.2 Communication Interface Connection
Connectivity cards allow the UPS to communicate in a variety of networking environment and with
different type of devices.
A. FACTORY DEFAULT: Standard Interface Card on UPS
B. OPTIONAL : Interface card with Relays
Options are listed below;
1. Serial Communication(Standard Hardware):RS232 Port (can be connected to External SNMP)
2. RS485 Interface (Standard Hardware)
3. Internal SNMP (Optional)
4. SNMP Switch
5. Emergency Power Off and Generator Connections
6. Dry Contacts (On Optional Interface Card)
