INFOSEC UPS SYSTEM X1 EX Series User Manual

INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 03 15 AA 59 204 31
10
1 1 . T E C H N I C A L S P E C I F I C A T I O N S
X1 EX- 500
X1 EX- 700
X1 EX- 1000
TECHNOLOGY
Technology
Line Interactive with AVR (microprocessor controlled)
Power
500 VA
700 VA
1000 VA
Output form
Modified Sine wave
Protection
Discharge / overcharge / overload
Power factor
0,5
0,5
0,5
PHYSICAL CHARACTERISTICS
Dimensions HxWxD
(mm)
142 x 101 x 300
Weight kg
3,7
4,4
5
Output connectors
2 Schuko/FR outlets
Optional USB port
INPUT TECHNICAL CHARACTERISTICS
Voltage
110/120 or 220/230/240 VAC
Voltage range
81-145 or 162-290 VAC
Frequency
50/60 Hz (auto sensing)
OUTPUT TECHNICAL CHARACTERISTICS (battery mode)
Voltage
110/120 or 220/230/240 VAC
Voltage regulation
± 10 %
Frequency
50/60 Hz ± 1 Hz
BATTERY
Battery
number & type
12V/4.5AH*1
12V/7AH*1
12V/9AH*1
Backup time
Up to 15 min (depending on connected load)
Recharging time
4-6 hours at 90% after complete discharge
ENVIRONMENT
Ideal Environment
0-40°C, 0-90% of relative humidity (without condensation)
NORMS
Security / Standard
CE RoHS
