Ingersoll-Rand RS18n User Manual

108 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

47629519

Revision C

May 2019

Save These Instructions

Contact-Cooled Rotary Screw Air Compressor

Product Maintenance Information

RS15ie, RS15ne, RS18ie, RS18ne, RS22ie, RS22ne,

RS11i, RS15i, RS15n, RS18i, RS18n, RS22i, RS22n

Product Maintenance Information

EN

Información de mantenimiento del producto

ES

Informations relatives à l’entretien du produit

FR

Informação sobre manutenção do produto

PT

RELEASED 23/May/2019 07:27:22 GMT

PRINT LANGUAGE

ENGLISH

SPANISH

FRENCH

PORTUGUES

Table of Contents

Questions and Answers:

S
Stacy SanchezAug 20, 2025
What to do if Ingersoll-Rand Air Compressor will not start?
- R
  Roger JonesAug 20, 2025
  If your Ingersoll-Rand Air Compressor won't start, first check if the power supply is switched on. If the power is on, then the controller might have failed, so check the supply to the controller and replace it if necessary. Alternatively, there could be a starter failure; in this case, isolate the supply, lock it off, tag it, and replace the failed component. If you are not sure how to do it, contact a qualified electrician or your local Ingersoll Rand representative.
B
Brooke YoungAug 22, 2025
What to do if Ingersoll-Rand Air Compressor is stopped and will not restart?
- B
  barbara99Aug 22, 2025
  If your Ingersoll-Rand Air Compressor is stopped and will not restart, it could be because the controller has tripped and hasn't been reset. Also, check if the emergency stop button has been pressed and not released; if so, identify the reason, repair the fault, disengage the button, and reset the controller. Another possibility is that the emergency stop button was pressed and released, but the controller hasn't been reset, so repair the fault and reset the controller. For more information, consult Tables 4 and 6.
D
danielsandovalAug 26, 2025
Why does my Ingersoll-Rand Air Compressor stop and will not restart?
- T
  Timothy JacksonAug 26, 2025
  Your Ingersoll-Rand Air Compressor might stop and not restart due to several reasons. The drive controller or the controller itself might have tripped the compressor. It's also possible that the maximum number of starts per hour has been exceeded. Refer to Tables 4 and 6 for detailed troubleshooting steps.
R
Rebecca FigueroaAug 27, 2025
What to do if my Ingersoll-Rand RS18n package draws too much current?
- D
  daniellejonesAug 28, 2025
  If your Ingersoll-Rand Air Compressor package is drawing too much current, it could be due to several reasons. First, check if the compressor is operating above the rated pressure and modify the settings accordingly. It's also possible that the separator filter element is dirty or blocked, in which case you should replace it. If the voltage supply is low or unbalanced, contact a qualified electrician or your local Ingersoll Rand representative. Finally, the airend might be damaged, which also requires contacting your local Ingersoll Rand representative.
S
Stephanie StanleyAug 29, 2025
Why is there high airend discharge temperature in my Ingersoll-Rand RS18n Air Compressor?
- L
  Lori RichAug 30, 2025
  A high airend discharge temperature in your Ingersoll-Rand Air Compressor can be caused by several factors. The compressor might be operating above its rated pressure, so check and adjust the settings. Low coolant level can also cause this, so check for leaks and top up the coolant. High ambient temperatures or insufficient cooling air can also contribute, so review the installation and system parameters and check the ducting and cooling air path. Lastly, a dirty or blocked coolant cooler can cause this issue, so clean or replace it. For further assistance, contact your local Ingersoll Rand representative.
E
eric72Aug 31, 2025
How to fix black residue on belt guard or airend of Ingersoll-Rand Air Compressor?
- C
  Craig BradyAug 31, 2025
  If you notice black residue on the belt guard or airend of your Ingersoll-Rand Air Compressor, it could be due to drive belt slippage, in which case you should replace the belt and gas spring. Another possibility is that the pulley is misaligned, so re-align it. Also, check for worn pulleys and replace the pulley and belt if necessary. If the gas spring has failed, replace it.
D
David BartlettSep 2, 2025
What to do if discharge air is contaminated with coolant in Ingersoll-Rand Air Compressor?
- P
  Paul MyersSep 2, 2025
  If the discharge air from your Ingersoll-Rand Air Compressor is contaminated with coolant, it could be due to several reasons. The scavenge pipe might be blocked, broken, or the o-ring isn't sealing, so clean or replace it. The separator element might be punctured, incorrect, require changing, or not sealing correctly, so replace it. If incorrect coolant has been added, drain the system, check for damage, clean it, and refill it with the correct coolant. If the system has been overfilled with coolant, check for damage and drain the excess.
R
Rebecca SweeneySep 4, 2025
What causes high dewpoint in Ingersoll-Rand RS18n Air Compressor?
- T
  Thomas MarshallSep 4, 2025
  A high dewpoint in your Ingersoll-Rand Air Compressor can be caused by several factors. Check if the refrigeration compressor is supplied with power and inspect the dryer protection fuse. Also, check the auxiliary contact on the main motor contactor and the operation of the drain valve and condensate check valves. A dirty condenser can also cause this issue, so clean the condenser and replace the panel filter element.
R
Robert GarciaSep 6, 2025
What causes ice formation in dryer of Ingersoll-Rand RS18n?
- M
  Maurice SchultzSep 6, 2025
  Ice formation in the dryer of your Ingersoll-Rand Air Compressor can be caused by low evaporator pressure. Check the hot gas valve setting to resolve this issue.
A
Anthony JohnsonSep 8, 2025
What to do if discharge air is contaminated with condensate in Ingersoll-Rand RS18n Air Compressor?
- C
  Carolyn HowardSep 8, 2025
  If the discharge air from your Ingersoll-Rand Air Compressor is contaminated with condensate, it could be due to the aftercooler not functioning correctly, so clean or replace it. Another possibility is a faulty moisture separator drain trap, which should be repaired or replaced. Continuous low speed or low ambient operation can also cause condensate buildup; in this case, review the system requirements and contact your local Ingersoll Rand representative.

Ingersoll-Rand RS18n Specifications

General

Brand	Ingersoll-Rand
Model	RS18n
Category	Air Compressor
Language	English

Summary

Safety

Routine Maintenance: Coolant Procedures

Routine Maintenance: Filters & Separators

Troubleshooting: Compressor Issues

General Faults

Common symptoms, causes, and remedies for compressor faults.

Discharge Air Too Hot

Air Contaminated with Coolant

Causes and solutions for coolant contamination in discharge air.

Ice Formation in Dryer

Causes and remedies for ice formation in the dryer.

Troubleshooting: Controller & VSD Issues

XE-70 Controller Faults

Common faults indicated on the XE-70 controller.

XE-50 Controller Faults

Common faults indicated on the XE-50 controller.

VSD Faults

Overview of VSD faults and their actions.

Integrated Dryer Maintenance

General Dryer Faults

Common faults and remedies for the dryer.

Water in the System

Troubleshooting dryer issues related to water in the system.

Disassembly of the Integrated Dryer

Decommissioning the Integrated Dryer
