Ingersoll-Rand RS22ie User Manual (English)

Questions and Answers:

K
Kaylee JonesAug 20, 2025
What to do if Ingersoll-Rand RS22ie will not start?
- C
  Cole MyersAug 20, 2025
  If your Ingersoll-Rand Air Compressor won't start, first check if the power supply is switched on. If the power is on, then the controller might have failed, so check the supply to the controller and replace it if necessary. Alternatively, there could be a starter failure; in this case, isolate the supply, lock it off, tag it, and replace the failed component. If you are not sure how to do it, contact a qualified electrician or your local Ingersoll Rand representative.
S
Stephen BlairAug 22, 2025
What to do if Ingersoll-Rand RS22ie Air Compressor is stopped and will not restart?
- M
  Matthew CardenasAug 22, 2025
  If your Ingersoll-Rand Air Compressor is stopped and will not restart, it could be because the controller has tripped and hasn't been reset. Also, check if the emergency stop button has been pressed and not released; if so, identify the reason, repair the fault, disengage the button, and reset the controller. Another possibility is that the emergency stop button was pressed and released, but the controller hasn't been reset, so repair the fault and reset the controller. For more information, consult Tables 4 and 6.
L
Leslie CoxAug 26, 2025
Why does my Ingersoll-Rand Air Compressor stop and will not restart?
- J
  Jeremiah HillAug 26, 2025
  Your Ingersoll-Rand Air Compressor might stop and not restart due to several reasons. The drive controller or the controller itself might have tripped the compressor. It's also possible that the maximum number of starts per hour has been exceeded. Refer to Tables 4 and 6 for detailed troubleshooting steps.
D
David FisherAug 28, 2025
What to do if my Ingersoll-Rand RS22ie Air Compressor package draws too much current?
- A
  April HarveyAug 28, 2025
  If your Ingersoll-Rand Air Compressor package is drawing too much current, it could be due to several reasons. First, check if the compressor is operating above the rated pressure and modify the settings accordingly. It's also possible that the separator filter element is dirty or blocked, in which case you should replace it. If the voltage supply is low or unbalanced, contact a qualified electrician or your local Ingersoll Rand representative. Finally, the airend might be damaged, which also requires contacting your local Ingersoll Rand representative.
G
Gerald RiveraAug 29, 2025
Why is there high airend discharge temperature in my Ingersoll-Rand RS22ie Air Compressor?
- J
  Jessica FletcherAug 30, 2025
  A high airend discharge temperature in your Ingersoll-Rand Air Compressor can be caused by several factors. The compressor might be operating above its rated pressure, so check and adjust the settings. Low coolant level can also cause this, so check for leaks and top up the coolant. High ambient temperatures or insufficient cooling air can also contribute, so review the installation and system parameters and check the ducting and cooling air path. Lastly, a dirty or blocked coolant cooler can cause this issue, so clean or replace it. For further assistance, contact your local Ingersoll Rand representative.
M
mortonbreannaAug 31, 2025
How to fix black residue on belt guard or airend of Ingersoll-Rand RS22ie?
- R
  reginafosterAug 31, 2025
  If you notice black residue on the belt guard or airend of your Ingersoll-Rand Air Compressor, it could be due to drive belt slippage, in which case you should replace the belt and gas spring. Another possibility is that the pulley is misaligned, so re-align it. Also, check for worn pulleys and replace the pulley and belt if necessary. If the gas spring has failed, replace it.
S
Susan MontoyaSep 2, 2025
What to do if discharge air is contaminated with coolant in Ingersoll-Rand RS22ie?
- L
  Lindsay PaceSep 2, 2025
  If the discharge air from your Ingersoll-Rand Air Compressor is contaminated with coolant, it could be due to several reasons. The scavenge pipe might be blocked, broken, or the o-ring isn't sealing, so clean or replace it. The separator element might be punctured, incorrect, require changing, or not sealing correctly, so replace it. If incorrect coolant has been added, drain the system, check for damage, clean it, and refill it with the correct coolant. If the system has been overfilled with coolant, check for damage and drain the excess.
S
Sally SimsSep 4, 2025
What causes high dewpoint in Ingersoll-Rand Air Compressor?
- K
  kimberly46Sep 4, 2025
  A high dewpoint in your Ingersoll-Rand Air Compressor can be caused by several factors. Check if the refrigeration compressor is supplied with power and inspect the dryer protection fuse. Also, check the auxiliary contact on the main motor contactor and the operation of the drain valve and condensate check valves. A dirty condenser can also cause this issue, so clean the condenser and replace the panel filter element.
A
Adam DurhamSep 6, 2025
What causes ice formation in dryer of Ingersoll-Rand Air Compressor?
- E
  Erica WilsonSep 6, 2025
  Ice formation in the dryer of your Ingersoll-Rand Air Compressor can be caused by low evaporator pressure. Check the hot gas valve setting to resolve this issue.
J
Jane SteinSep 8, 2025
What to do if discharge air is contaminated with condensate in Ingersoll-Rand RS22ie?
- R
  Rita HamiltonSep 8, 2025
  If the discharge air from your Ingersoll-Rand Air Compressor is contaminated with condensate, it could be due to the aftercooler not functioning correctly, so clean or replace it. Another possibility is a faulty moisture separator drain trap, which should be repaired or replaced. Continuous low speed or low ambient operation can also cause condensate buildup; in this case, review the system requirements and contact your local Ingersoll Rand representative.

Ingersoll-Rand RS22ie Specifications

General

Brand	Ingersoll-Rand
Model	RS22ie
Category	Air Compressor
Language	English

Summary

About This Manual

Safety

Essential safety precautions and procedures for operating and maintaining the compressor.

Air Compressor Maintenance

Maintenance Chart

Detailed schedule of maintenance tasks based on operating hours or intervals.

Routine Maintenance

Procedures for periodic maintenance of various compressor components.

Troubleshooting

Compressor will not start.

Troubleshooting steps for when the compressor fails to initiate operation.

Compressor stops and will not restart.

Diagnosing issues when the compressor stops and cannot be restarted.

Compressor is stopped and will not restart.

Troubleshooting steps for a compressor that has stopped and remains inactive.

Compressor will not meet pressure required by system.

Steps to resolve issues where the compressor fails to maintain system pressure.

Pressure produced by compressor is too high due to speed not reducing as demand reduces (VSD only).

Troubleshooting VSD specific issue where discharge pressure is too high.

Compressor discharge air too hot.

Diagnosing and resolving causes of hot discharge air from the compressor.

Discharge air is contaminated with coolant.

Steps to identify and fix coolant contamination in the compressor's discharge air.

Compressor package draws too much current.

Diagnosing issues leading to excessive current draw by the compressor package.

Emergency stop.

Troubleshooting the emergency stop fault indication on the controller.

Fan motor overload.

Diagnosing and resolving fan motor overload faults.

High airend discharge temperature.

Troubleshooting high discharge temperature faults indicated by the controller.

Remote start failure.

Troubleshooting issues preventing the remote start function from operating.

Remote stop failure.

Troubleshooting issues preventing the remote stop function from operating.

Sensor failure.

Diagnosing faults related to sensor failures within the system.

Controller has tripped the compressor.

Troubleshooting faults where the controller has initiated a compressor trip.

Invalid calibration.

Steps to address faults related to invalid calibration readings.

Low sump pressure.

Troubleshooting causes of low sump pressure.

VSD communication failure.

Troubleshooting communication failures between the VSD and controller.

VSD initialization fault.

Diagnosing initialization faults specific to the Variable Speed Drive (VSD).

Change separator element and/or high sump pressure.

Troubleshooting separator element issues and high sump pressure.

Motor current fault.

Troubleshooting faults related to motor current readings.

CT failure

Diagnosing issues related to Current Transformer (CT) failure.

High Airend Discharge Pressure

Troubleshooting high discharge pressure warnings from the XE-50 controller.

Power Failure Detected

Diagnosing power failure detection alerts from the XE-50 controller.

Emergency Stop

Troubleshooting emergency stop alerts from the XE-50 controller.

Main or Blower Motor Overload

Diagnosing main or blower motor overload alerts from the XE-50 controller.

Pressure Sensor Fault

Troubleshooting pressure sensor fault alerts from the XE-50 controller.

Temperature Sensor Fault

Excess Temperature

Power Supply 24V DC Low

Power Supply Analog Inputs Low

High Airend Discharge Temperature

Troubleshooting high discharge temperature warnings (above 103°C) from XE-50.

High Disch Pres

Troubleshooting high discharge pressure alerts indicated by the XE-50 controller.

Invalid Cal

Overload

Main Motor OL

Rem Start Fail

Rem Stop Fail

4APT Failure

High VSD Ambient Temperature

Troubleshooting high ambient temperature faults for the VSD.

VSD Comm Fail

Troubleshooting VSD communication failures.

Stop Failure

Drive Init Error

Internal Fault

Low Supply Voltage

High DC Link Voltage

DC Over-voltage

Phase Missing

Mains Phase Loss

Phase Imbalance

Short Circuit

Motor Thermal Overload

Troubleshooting motor thermal overload faults for the VSD.

Over Current

Diagnosing over current faults for the VSD.

Ground Fault

Inrush Fault

Heatsink Temp

Torque Limit Current Limit
