C.C.N. : 80445273

REV. : A

DATE : OCTOBER 2008

SSR UP5-4, UP5-5.5, UP5-7.5, UP5-11c

50 Hz

SSR UP6-5, UP6-7.5, UP6-10, UP6-15c

60 Hz

OPERATION AND MAINTENANCE MANUAL

This manual contains

important safety information

and must be made available

to personnel who operate

and maintain this machine.

Refer all communications to the nearest Ingersoll Rand Full Service Distributor.

Table of Contents

Questions and Answers:

C
Chad GonzalezAug 8, 2025
What to do if the drain timer is not working on my Ingersoll-Rand SSR UP6-5 Air Compressor?
- J
  Jonathan DelgadoAug 8, 2025
  If the drain timer on your Ingersoll-Rand Air Compressor isn't working, here's what might be happening and how to address it: 1. **No electrical supply:** Ensure the unit is receiving power. 2. **Timer malfunction:** The timer itself may be faulty and need replacement. 3. **Clogged port:** A blocked port can prevent operation; try cleaning the valve. 4. **Solenoid valve malfunction:** The solenoid valve could be defective, requiring replacement. 5. **Clogged strainer:** A blocked strainer may be the issue; clean the strainer.
D
Dawn WilsonAug 16, 2025
Why won't the solenoid condensate valve close on my Ingersoll-Rand SSR UP6-5?
- J
  John HuynhAug 16, 2025
  If the solenoid condensate valve on your Ingersoll-Rand Air Compressor won't close, it could be due to a couple of reasons. First, debris might be preventing the diaphragm from seating properly; in this case, you should remove the solenoid valve, disassemble it, clean all the parts, and then reassemble it. Alternatively, there could be a short in an electrical component. Check the power cord or timer and replace them if necessary.
D
David JimenezAug 23, 2025
Why timer will not activate on my Ingersoll-Rand Air Compressor?
- E
  Edward JohnsonAug 23, 2025
  If the timer on your Ingersoll-Rand Air Compressor won't activate, there are several potential causes. First, ensure that the unit is receiving electrical power by verifying the power supply. If power is present, the timer itself may be malfunctioning and require replacement. Additionally, a clogged port or strainer could be preventing activation; try cleaning the valve and strainer. Finally, a malfunctioning solenoid valve could be the culprit, in which case it should be replaced.
T
Thomas SmithAug 31, 2025
What to do if valve will not close on my Ingersoll-Rand Air Compressor?
- J
  Jennifer HopkinsAug 31, 2025
  If the valve on your Ingersoll-Rand Air Compressor won't close, it could be due to debris in the solenoid valve preventing the diaphragm from seating properly. To resolve this, remove the solenoid valve, disassemble it, thoroughly clean all components, and then reassemble it. Alternatively, a short in an electrical component, such as the power cord or timer, could be the cause. Inspect these components and replace them as necessary.

Ingersoll-Rand SSR UP6-5 Specifications

General

Brand	Ingersoll-Rand
Model	SSR UP6-5
Category	Air Compressor
Language	English

Summary

Safety Precautions

General Safety Precautions

Covers general safety rules, warnings, and precautions for operating the compressor.

Installation and Handling

Unit Dimensions and Views

Diagrams showing external dimensions and mounting points of the unit.

80 Gallon Tank Mounted Dimensions

Detailed dimensions for the 80-gallon tank-mounted model.

120 Gallon Tank Mounted Dimensions

Detailed dimensions for the 120-gallon tank-mounted model.

272 Litres Tank Mounted Dimensions

Detailed dimensions for the 272-litre tank-mounted model.

500 Litres Tank Mounted Dimensions

Detailed dimensions for the 500-litre tank-mounted model.

Technical Specifications (60Hz UP6 Series)

Performance and data specifications for 60Hz UP6 series compressors.

Technical Specifications (50Hz UP5 Series)

Performance and data specifications for 50Hz UP5 series compressors.

Operating Instructions

General Operation Overview

Basic principles of compressor operation, design, and cooling.

Compressor Controls and Dual Control

Explains compressor controls, pressure switch, and dual control options.

Control Panel and Startup Procedures

Maintenance

UP Series Maintenance Schedule

Routine Maintenance Safety and Procedures

Troubleshooting

Start-up and Operation Problems

Troubleshooting common issues like failure to start, shutdowns, and current draw.

Coolant, Noise, Seals, and Valve Issues

Addresses problems with coolant, noise, shaft seals, and valve malfunctions.
