IDS400 INSTALLER MANUAL NO. 700-204-02A ISSUED NOV 2000 VER 1.01 9
IDS400 INSTALLER MANUAL
5. The Key-Switch or Remote Control Unit
A momentary key-switch or non-latching remote control receiver may
be connected to any zone to allow remote arm/disarm capability and
or remote panic.
v If a key-switch or remote control unit is used, a 3K3 resistor must
be connected between the zone input and ground.
v Use a normally open,
spring-loaded momentary
key-switch or a
non-latching
remote control unit. The remote receiver must provide
a pulsed output.
v If using a key-switch, program the zone as an Arm/Disarm zone.
v If using a remote control, program the zone as either a Paniczone
or an Arm/Disarm zone, as required.
v The panel will arm instantly (no entry/exit delay) when arming by
means of a key-switch or remote control unit.
6. Additional Technical Data
v Use a suitable transformer with an output voltage of 15 volts AC
±10% with a 16VA minimum rating. A 32 VA transformer is
preferable for larger installations.
v Use a 12v sealed lead acid battery, min. 3ah. The back up period
after mains failure will depend on the number of keypads, sensors
and peripheral devices attached to the system. The current drawn
by the panel and keypad (no indicators illuminated) excluding
sensors is 240mA.
v The panic zone provided on the keypad is not an end-of-line
supervised zone and requires a normally open panic switch. If
using this panic zone connect a normally open panic switch
between the PAN terminal and the GND terminal. If this zone is
not used leave the terminal open circuit.
