InMode MD CONTOURA - Section 13 - System Specifications

CONTOURA Operator Manual 44
Section 13 - System Specifications
Input Power
Main Line Frequency
(nominal)
Input Voltage (nominal)
Input Current (rms)
50 - 60 Hz
100 - 240 VAC
2 A
Operating Parameters
Ambient Temperature Range
Relative Humidity
Atmospheric Pressure
Warm-up Time
15° – 35° C [59° – 95° F]
30% to 80%, non-condensing
90 - 110 kPa
If transported or stored at temperatures outside the
operating temperature range, allow one hour for the
system to reach room temperature before use.
Transport and Storage
Ambient Temperature Range
Relative Humidity
Atmospheric Pressure
-20° – 65° C [35° – 131° F]
0% - 80%, non-condensing
50 - 110 kPa
Dimensions
System
Handpiece cable
35 cm W x 35 cm D x 100 cm H
250 cm L
[18.2’’ W x 18.2’’ D x
40’’ H]
[100`` L]
Weight
System
Handpiece
20 Kg
0.2 Kg
[44 lb]
[0.4 lb]
Output Parameters
RF Power
RF Frequency
Tissue impedance
Up to 60 W
1 MHz
50 -600 Ohm
