Technical data
Operating instructions
Geometry
Dimensions:
Installation:
Weight:
(H x W x D) 660 x 240 x 150 mm
Wall mounting
innogy eBox: approx. 5 kg
Protection class IP54
Temperature range − 25 °C to + 40 °C
Grid connection
Power supply:
Required connected load:
400 V 3~ + PE+N from sub-distribution
• 11 kW; maximum power
• Single-phase connection also possible (3.7 kW)
Charging points
No. of charging points:
Output:
Socket:
Single charging point
11 kW (400 V 3~, 16 A)
Type 2 socket (3~ + N + Pe + pilot + proximity)
pursuant to IEC 62196-2 with plug lock
Display Multicoloured LED indicates charging,
charge status and error message
Protection technology Residual current device Type B (30 mA for AC residual
currents and 6 mA for DC residual currents) and circuit breaker
separate in sub-distribution (not included in scope of delivery)
Authentication/
activation
Via key switch
Communication Pilot signal pursuant to IEC 61851-1:2012
Foil wrapping Weather and graffi ti-resistant foil
(optionally available)
Access authorisation
(installer)
Special screws, special tools required
Additional
convenience functions
The functional design of the casing allows the charging cable to be
hung over the charging box following completion of charging
!
