MCAC-UTSM-2010-10 Test Operation
Installation 17
3. Indoor unit installation
3.1 Ceiling & floor indoor unit installation
3.4.1 Service space for indoor unit
3.4.2 Bolt pitch
Ceiling installation
Capacity (Btu/h)
D E
36K 1200 220
48K, 60K 1565 220
Wall-mounted installation
