CONFIDENTIAL
and PROPRIETARY
96-09302-00-01 revA DCR 19-030 21-Mar-2019 INOGEN ONE G5 TECHNICAL MANUAL
Page 6 of 18
2.4.2. Trigger sensitivity
The conserver will trigger when the negative pressure at the internal sensor reaches -
0.12 cm H
2
0 (+/- 20%). This low trigger sensitivity allows for breath detection of very
shallow breathing, but may also result in the occasional trigger due to motion of the
cannula or motion of the concentrator. The trigger sensitivity may vary.
2.4.3. Flow Setting Selection Relative to Physician Prescription
Inogen has labeled each of the six settings to provide a guideline for matching the setting
of the device to the continuous flow prescription issued by the physician. Actual
correlation is dependent upon the patient’s breathing rates, inspiratory tidal volume, and
other physiologic factors. Inogen suggests that each patient be titrated (a) while
sedentary, and (b) while active or ambulatory.
3. SERVICING THE INOGEN ONE G5
3.1. Maintenance by the Provider
3.1.1. Authorized Repair Centers
The Inogen One G5 is only intended to be repaired by authorized repair centers. If a
repair is required, please contact Inogen to locate your nearest authorized repair center.
If you would like to become an authorized repair center, please contact Inogen for access
to certification training, service instructions, component part lists and the necessary repair
equipment.
NOTE
Do not disassemble the Inogen One G5 or any of the accessories or attempt any
maintenance other than tasks described in this Technical Manual unless you
have completed a training course through Inogen. Disassembly of the Inogen
One G5 or any of the accessories without proper training certification will void
the product warranties. Contact Inogen for information about receiving proper
training and certification for service of the Inogen One G5 and accessories.
3.1.2. Suggested Materials for Regular Maintenance
To perform regular field maintenance (by a technician) on the Inogen One G5 System,
you may need:
o Inogen One G5 Particle Filter (RP-500)
o Output Filter Replacement Kit (RP-404)
Includes spanner wrench and two output filters
o Inogen One G5 Column Pair (RP-502)
o Inogen One G5 Batteries (BA-500, BA-516)
o Nasal Cannula (Salter Labs 16SOFT or equivalent)
o External Oxygen Analyzer (such as Salter Labs PrO2 Check)
NOTE
During a normal field maintenance visit, the technician may elect to turn off the
concentrator for approximately 30 minutes. If the patient requires oxygen during
