1.3 Specifications
■ Power supply specifications
Item Specification
Rated bus input voltage 5 VDC (4.75 VDC to 5.25 VDC)
Rated bus input current 120 mA (typical@5 V)
Rated terminal input voltage 5 VDC (20.4 VDC to 28.8 VDC)
Rated terminal input current 100 mA (typical@24 V)
Rated terminal output voltage N/A
Rated terminal output current N/A
Hot swap Not supported
■ Output specifications
Item Specification
Output type Analog output
Output mode Voltage/Current
Output channels 4
Resolution 16‑bit
Conversion time 60 us/ channel
Output voltage range ±10 V, 0 to 10 V, ±5 V, 0 to 5 V, 1 to 5V
Voltage output load 1kΩ
Voltage output accuracy (25°C) ±0.1% (full range)
Voltage output accuracy (full temperature
range)
±0.5% (full range)
Voltage output diagnosis Supports short circuit detection,
overtemperature protection
Output current range 0 to 20 mA, 4 to 20 mA
Current output load 0‑600Ω
Current output accuracy (25°C) ±0.1% (full range)
