Chapter 1 Product Information
1.1 Servo Drive
1.1.1 Designation Rules and Nameplate
Figure 1-1 Designation rules and nameplate of servo drive
IS650 P T 025 I U X
- A
Customized
Specification
Mark
16-bit analogA
E-cam, gantry
synchronization
M
CANlinkC
CANopenCO
Version
Mark
X versionX
Y versionY
Encoder Type
Mark
Incremental encoderU
Mounting Method
Mark
I
Substrate installation
(standard)
Rated output
current
Mark
32A
032
37A
037
25A
025
IS650
Servo drive
Mark
Series
Product Type
Mark
P
Pulse
Mark
Voltage Class
T
380 V
60A
060
112
112A
45A
045
B
Large
volume
Table 1-1 IS650P rated current
Drive Model
IS650P□□□IUX
Rated Input Current (A) Rated Output Current (A) Max. Output Current (A)
SIZE-G
T025 20 25 46.75
T032 24 32 59.84
T037 30 37 69.19
T045 36 45 84.15
SIZE-H T060 48 60 112.2
SIZE-I
T075 63 75 140.25
T091 76 91 170.17
T112 95 112 209.44
