Glossary
Components:
Desk leg (DL) The lifting columns, typically with powder coated steel proles, responsible for lifting the working load of the application.
Control box (CBD6S) Both the computer and power supply of the system.
Desk panel (DP) The user interface. Depending on the model, it is used to activate the application, set memory positions,
display the height, display error codes, connect to mobile apps, and give reminders to the user.
Motor cable Transmits low voltage power (18-39 VDC) from the control box to the desk legs,
and also transmits Piezo signals when available from the desk leg.
Mains cable Transmits high voltage power (120 VAC in US and Canada) to the control box.
Other:
Initialize Procedure to reset all desk legs to the fully retracted position so that the control box knows where they are.
Reference Any group of desk legs that run in parallel when an Up or Down command is sent to the control
box. It is possible to have a custom control box conguration that allows for more than one
Reference. [Example: Two (2) desk legs on Reference #1 (Channels #1 and #2) to lift a work
surface, and one (1) LA31 on Reference #2 (Channel 3) to adjust a monitor array.]
Height Adjustable Table – User Guide | October 2019 3
