INSIGHT DA025 - 页面 14

11
NOTE: WRENCH TIGHTEN SCREWS.
STEP 3 | USER FRAME INSTRUCTIONS & NOTES
70
13
20
7
12
61
36
6
29
36
61
8
58
22
92
97
75
ITEM NO DESCRIPTION QTY
1
1
1
1
1
1
1
1
4
2
2
4
2
2
2
20
13
8
12
7
6
22
29
36
58
61
92
75
70
97
Movement Arm
Adjustable Cam
Swing Tube
Cam Support Tube
Flange
Pivot
Counter Poise Block
Pivot
Cap
Bronze Bearing
Flat Head Cap Screw M10*25
Socket Set Screw M8*10
Flat Washer
Spring Washer
Hex Bolt M10*30
