INSIGHT DA025 User Manual

ITEM NO DESCRIPTION QTY ITEM NO DESCRIPTION QTY
1 Weight Stack Frame 1 49 Plug φ50 1
2 Standing Main Frame 1 50 Pulley 1
3 Top Frame 1 51 Rubber Foot 4
4 Seat Support 1 52 Handle Ball 1
5 Main Bracket 1 53 Grip 2
6 Movement Arm 1 54 Spacer 2
7 Adjustable Cam 1 55 Cable_1 1
8 Swing Tube 1 56 Flange Bearing 4
9 Back pad support 1 57 Bronze Bushing 2
10 Adjustable tube 1 58 Bronze Bearing 2
11 handle 1 60 Bronze Bearing1 4
12 Cam Support Tube 1 61 Flat Head Cap Screw M10*25 8
13 Flange 2 62 Buon Head Cap Screw M6*12 2
16
Handle Frame 1 63 Buon Head Cap Screw M8*45 1
17 Adjustable Support 1 64 Buon Head Cap Screw M8*60 1
18 Front Shroud 1 65 Socket Head Cap Screw M4*15 1
19 Rear Shroud 1 66 Socket Head Cap Screw M8*20 2
20 Pivot 1 68 Socket Head Cap Screw M8*25 3
21 Adjustment Plate 1 69 Socket Set Screw M5*3 8
22 Counter Poise Block 1 70 Socket Set Screw M8*10 4
23 Sha 1 71 Self-tapping screw 4
24 Spring 1 73 Hex Bolt M10*20 8
25 Hex Nut M20 1 74 Hex Bolt M10*70 3
26 Ch
ain 1 75 Hex Bolt M10*30 8
28 Pop Pin 1 76 Hex Bolt M10*50 2
29 Pivot 1 77 Hex Bolt M10*75 1
30 Seat Pad Plate 1 78 Hex Bolt M10*80 1
31 Cable Retainer Bracket 2 79 Hex Bolt M10*95 2
32 Guide Rod 2 80 Hex Bolt M10*125 6
33 Mount Sleeve 2 81 Hex Bolt M10*130 4
34 Pulley Spacer 2 84 Hex Bolt M12*35 4
35 Torsion Spring 1 85 Nut M10 4
36 Cap 4 86 Hex Nut M6 2
37 Aluminium Grip Ring 4 87 Nylon Lock Nut M8 4
38 Aluminium Cap 2 88 Nylon Lock Nut M10 22
39 Aluminium Grip R
ing 2 89 Nylon Lock Nut M12 7
40 Aluminium Cap 2 90 Flat Washer 11
41 Seat Pad 1 91 Flat Washer 8
42 Back Pad 1 92 Flat Washer 56
43 Foam 2 93 Weight Stack 15
44 Pulley 3 94 Top Plate 1
45 Plug RT50 5 95 Selector Pin W/Coil 1
46 Plasc Tube Guide 2 96 Weight Rubber Bumper 2
47 Top Shroud 1 97 Spring Washer 2
48 Spacer 3 98 Spring Washer 2
