INSIGHT DA025 - Page 16

16
NOTE: WRENCH TIGHTEN SCREWS.
STEP 8 | USER FRAME INSTRUCTIONS & NOTES
73
92
19
18
88
92
71
47
75
92
ITEM NO DESCRIPTION QTY
4
2
4
2
6
1
1
1
75
88
92
73
47
71
19
18
Front Shroud
Rear Shroud
Top Shroud
Self-tapping screw
Hex Bolt M10*20
Hex Bolt M10*30
Nylon Lock Nut M10
Flat Washer
