NS-AC10PWH9 / NS-AC12PWH9 / NS-AC10PWH9-C / NS-AC12PWH9-C
www.insigniaproducts.com
3 Install the window sealing plate in the window opening, adjusting the length to fit the window opening and securing it
with screw A (provided).
4 Insert the hose adapter into the vent panel, then slide the adapter until it clicks into place.
Note:
• The window sealing kit works with casement, sliding, and vertical, double-hung windows.
• You do not need to remove your window screen.
Screw A
Small gap
Insert
Slide
