13
3-in-1 HEPA 16" Air Purifier
www.insigniaproducts.com
Troubleshooting
Specifications
PROBLEM SOLUTION
My air purifier does not work. • Make sure your air purifier is plugged in.
• Make sure the power outlet is working.
• Make sure your air purifier is turned on.
• If your air purifier is plugged into a surge protector,
make sure that it is turned on.
My air purifier has poor air flow
or is loud.
• Make sure your air purifier is on a flat surface.
• Make sure nothing is blocking the air inlet and filtered
air outlet. Position your air purifier at least 1 foot
(.3 meters) away from walls or large objects.
• Check the condition of the filters. Replace them if they
are dirty.
• Remove the plastic bag from the HEPA filter.
• Make sure the filters are seated properly.
My HEPA filter and pre-filter do
not last the full lifetime.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter.
My filter indicator is flashing
blue and/or red.
• When the filter indicator LED flashes blue, you need to
check and replace your pre-filter.
• When the filter indicator LED flashes red, you need to
check and replace your HEPA filter.
• When the filter indicator LED flashes blue and red, you
need to check and replace both filters.
Dimensions (H×W×D) 17.6 × 6.7× 8.9 in. (44.7 × 17.0 × 22.5 cm)
Weight 6.2 lbs. (2.8 kg)
Power input 120V AC
Power cord length 5.9 ft. (1.8 m)
Operating temperature 40~110°F (4~43°C)
Coverage area 108.0 sq. ft. (10.0 m
2
)
HEPA filter lifetime 3000 hours
Pre-filter lifetime 1500 hours
HEPA filter dimensions
(H×W×D)
10.0 × 4.7 × 1.1 in. (25.5 × 12.0 × 2.7 cm)
Pre-filter dimensions
(H×W×D)
10.3 × 5.1 × .2 in. (26.2 × 13.0 × .5 cm)
Pre-filter technology Activated carbon mesh
Pre-filter model number NS-APPF168
HEPA filter model number NS-APF168
NS-AP16BK8_17-0692_MAN_V1_ENG.fm Page 13 Wednesday, September 20, 2017 10:15 AM
