12
Insignia Ceramic Tower Heater
www.insigniaproducts.com
Troubleshooting
Specifications
Caution
Do not try to repair your heater yourself. Doing so invalidates the
warranty.
Problem Possible cause Possible solution
Your heater shuts
off unexpectedly
or fails to operate
There is no power. Make sure that the heater is plugged in and that the electrical outlet
is working.
The set temperature is lower than
the current room temperature.
Set the desired temperature higher than the current temperature to
restart the heater.
Room temperature has reached
the temperature set on the
temperature control dial.
• This is normal. The heater restarts when room temperature is
lower than the set temperature.
• Adjust the temperature control dial setting if it's not set to your
desired temperature.
One of the safety protection
devices was activated to prevent
overheating.
1. Place the heater in an upright position.
2. Check for any obstructions. If you find an obstruction, turn the
heater off.
3. Unplug the heater and wait at least 10 minutes for it to cool down.
4. Carefully remove the obstruction. Plug the heater in and restart it
as described in “Using your heater” on page 9.
5. If you still notice the same problem, remove the plug from the wall
and have the heater checked by an authorized service person.
The room is not
warm enough
The room is too large or a window
is open.
• Turn on the main heat source for the room.
• Use more portable heaters.
•Close the window.
The temperature is set too low. • Increase the temperature setting.
The power setting is too low. • Select a higher power setting.
Model number NS-HTTCBK6
Voltage 120 VAC
Frequency 60 Hz
Power 1500 Watts
Noise level ≤ 50 dB
Dimensions 9.8 x 9.8 x 31.5 in. (250 x 250 x 800 mm)
Remote control battery CR2302 Lithium button
NS-HTTCBK6_15-0373_MAN_V1_ENG.fm Page 12 Friday, May 8, 2015 11:03 AM
