Insignia NS-HTVMF0C User Manual

FIXED-POSITION WALL MOUNT FOR TVs 40-70 in.
11
www.insigniaproducts.com
• DO NOT over-tighten the lag bolts (11).
You’ll need
3 in.
75 mm)
* Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 11/2 x 31/2 in. (38 x 89 mm).
* Minimum horizontal spacing between fasteners cannot be less than 16 in. (406 mm).
Align the center of the
template with the height mark
(a+b) you made in step 4.
Edge-to edge
stud finder
11 (2)
Drill
7/32 in. wood drill bit
1/2 in. socket
wrench
Wall plate (10)
12 (2)
Wall plate template (R)
Tape
Wall mount template

Level
