Insignia NS-HTVMF0C User Manual

12
www.insigniaproducts.com
STEP 5 - Option 2: Installing on a solid concrete or concrete
block wall (requires Concrete Installation Kit CMK1)
CAUTION:To prevent property damage or personal injury, never drill into the mortar between the
blocks. Mount the wall plate directly onto the concrete surface.
1 Align the center of the wall plate template (R) at the height (a + b - 1.5 in.) you determined in the
previous step, make sure that it is level, then tape it to the wall.
2 Drill two pilot holes through the template to a depth of 3 in. (75 mm) using a 3/8 in. (10 mm) diameter
masonry drill bit, then remove the template.
3 Insert the concrete wall anchors (C3) into the pilot holes and use a hammer to make sure the anchors are
flush with the concrete surface.
4 Align the wall plate (10) with the anchors, insert the lag bolts (C1) through the lag bolt washers (C2),
then through the holes in the wall plate. Tighten the lag bolts only until they are firm against the wall
plate.
CAUTION:
• Use only the upper slotted holes to mount the wall plate. Do not use the lower slotted holes.
