Insignia NS-IMK20WH7 User Manual

11
Ice Maker
www.insigniaproducts.com
13 Reinstall the freezer shelf and set the ice storage bin on the shelf.
14 Locate the pre-punched holes at the bottom right corner of the back
panel of the refrigerator. Align the bracket of the water valve with the
factory drilled holes, then use a Phillips head screwdriver to drive the
two self-drilling screws through the bracket and into the cabinet.
Ice storage
bin
Water valve
Factor y
pre-punched
holes
Self-drilling
screws
NS-IMK20WH7_16-0335_MAN_V1_ENG.fm Page 11 Tuesday, May 31, 2016 11:59 AM

Insignia NS-IMK20WH7 Specifications

General

Brand	Insignia
Model	NS-IMK20WH7
Category	Ice Maker
Language	English
