Insignia NS-IMK20WH7 User Manual

10
NS-IMK20WH7
www.insigniaproducts.com
11 Mount the ice maker onto the two ice maker mounting screws you
installed in step 9. Make sure that the water inlet tube is sitting inside
the fill cup, then tighten the screws.
12 Adjust the leveling bracket to level the ice maker. The ice maker is level
when the gap between the freezer wall and the ice maker is the same
at the top and bottom.
Ice maker
mounting screws
Fill cup
Water inlet tube
Ice maker
Screws
Leveling bracket
NS-IMK20WH7_16-0335_MAN_V1_ENG.fm Page 10 Tuesday, May 31, 2016 11:59 AM

Insignia NS-IMK20WH7 Specifications

General

Brand	Insignia
Model	NS-IMK20WH7
Category	Ice Maker
Language	English
