9
Ice Maker
www.insigniaproducts.com
10 With the ice maker in one hand, plug the wiring harness connector
into the terminal located at the top of the freezer panel. Make sure that
the connection is tight. Make sure the wiring harness is still in the hook
on the back of ice maker.
Wiring harness
connector
Ter mi na l
