Assembling your desk
STEP 1: Attach the leg frames and bottom support bar
You n e ed :
1 Align a leg frame (2) with the holes on a side of the desktop, making sure that the hole near the foot is toward the
back of the desktop.
2 Insert two M6 × 45 mm bolts (A) through the leg frame and into the desktop (1) and tighten with the hex wrench
(F).
3 Repeat steps 1–2 to attach the other leg frame.
4 Align the bottom support bar (3) with the holes on the bottom of the leg frames, then secure with two M6 × 45 mm
bolts (A) using the hex wrench (F). Make sure that the holes on the side of the support bar face the back of the
desktop (as shown).
Note: If the bottom support bar does not fit between the two leg frames, loosen the bolts to let the pieces move more freely.
3
Bottom support bar
1
Desktop
2
Leg frames (2)
A
M6 × 45 mm bolts (6)
F
Hex wrench
B
a
c
k
wa
rd
F
o
r
wa
rd
To Next Page
