www.insigniaproducts.com
16
26.3 Cu. Ft. Side-by-Side Refrigerator
3 Connect the 1/4" extension tubing (included) to the shutoff valve.
4 Turn the main water supply back on, then turn on the shutoff valve and flush out the tubing until the water runs clear.
5 Turn off the shutoff valve.
Note: The initial dark discoloration of water is normal.
Shutoff valve
Cold water line
Pipe clamp
Water line installation kit
