www.insigniaproducts.com
14
10.5 Cu. Ft. Top Mount Refrigerator
18 Remove the screw that secures the hinge screw hole cover from the top left side of the cabinet, then remove the cover
and install it on the top right side of the cabinet.
19 Secure the upper hinge to the top left side of the cabinet with the three screws you removed previously. Before you
tighten the upper hinge screws, make sure that the top of the door is level with the cabinet and that the rubber gasket
makes a good seal.
20 Install the hinge cover over the hinge on the top left side of the cabinet.
Screw
Hinge screw hole cover
Hinge cover
Screws
Upper hinge
