Insignia NS-RTM10BK0 User Manual

www.insigniaproducts.com
13
NS-RTM10BK0/NS-RTM10WH0/NS-RTM10SS0
14 Install the center hinge to the left side with the two screws you removed previously.
15 Remove the screw that secures the door stops from the bottom of the freezer door, then remove the door stops and
install them on the bottom left side.
16 Install the freezer compartment door.
17 Remove the door bushing hole cover on the top left side of the freezer compartment door, then move the door
bushing from the top right of the door to the top left of the door. Install the hole cover in the bushing hole on the top
right of the door.
Screws
Center hinge spacer
Center hinge
Door bushing
Door stops
Freezer door
Door bushing
Bushing hole cover
Refrigerator door

Insignia NS-RTM10BK0 Specifications

General

Brand	Insignia
Model	NS-RTM10BK0
Category	Refrigerator
Language	English
