www.insigniaproducts.com
12
10.5 Cu. Ft. Top Mount Refrigerator
10 Remove the screw that secures the door stops from the bottom right of the refrigerator compartment door, then
remove the door stops and install them on the bottom left side.
11 Install the refrigerator compartment door.
12 Remove the door bushing hole cover on the top left side of the refrigerator door, then move the door bushing from the
top right of the door to the top left of the door. Install the hole cover in the bushing hole on the top right of the door.
13 Remove the center hinge screw hole plugs on the left side of the cabinet, then install the plugs in the screw holes on
the right side of the cabinet.
Refrigerator compartment door
Door stops
Door bushing
Bushing hole cover
Refrigerator door
Screw hole plugs
