11
9.9 and 11.5 cu. ft. Top Mount Refrigerator
www.insigniaproducts.com
1 Unplug your refrigerator and remove all food from the door shelves.
2 Remove the top cap and the top hinge cover, then unscrew and
remove the top hinge and shim. Keep the screws to reuse.
3 Lift the freezer door up and away from your refrigerator.
Top cap
Top hinge cover
Top hinge
Top hinge shim
NS-RTM10WH7_NS-RTM10BK8_NS-RTM10WH7-C_NS-RTM12SS7-C_17-0191_MAN_V3_ENG.fm Page 11 Tuesday, April 11, 2017 3:10 PM
