12
NS-RTM10WH7/NS-RTM10BK8/NS-RTM10WH7-C/NS-RTM12SS7-C
www.insigniaproducts.com
4 Unscrew the two screws holding the center hinge, remove the hinge
and center hinge shim, then lift the refrigerator door up and away
from your refrigerator. Save the screws to reuse.
5 Unscrew the two screws holding the bottom right hinge, then remove
the bottom right hinge.
Center hinge shim
Center hinge
Remove the bottom right hinge
Attach the bottom left hinge
NS-RTM10WH7_NS-RTM10BK8_NS-RTM10WH7-C_NS-RTM12SS7-C_17-0191_MAN_V3_ENG.fm Page 12 Tuesday, April 11, 2017 3:10 PM
