10
45 Bottle Wine/Beverage Cooler
www.insigniaproducts.com
5 Unscrew the pins from both hinges and transfer them to threaded holes
on the opposite sides of the hinges, then reinstall the bottom hinge in
bottom left corner of the cabinet using the same three screws you
removed.
6 On the bottom edge of the door, move the door stop bracket and bushing
to the holes on the opposite side.
7 On the top edge of the door, move the button plugs and bushing to holes
on opposite side.
8 Place bottom left corner of the door onto lower hinge, then install the top
hinge to onto the cabinet. Make sure that the door is level and seals
properly against the cabinet, then tighten the three screws.
9 Snap top cap back onto the hinge.
